Fieldpiece SM380VINT 2-Valve Digital Manifold with Vacuum Gauge
by Fieldpiece
$1,025.50
The Fieldpiece SM380VINT is a wireless, data-logging digital manifold with a built-in micron gauge, temperature-compensated system tightness test, and a large backlit display — built for 240V/AU markets and A2L-ready.
Key Features
- 2-valve configuration with built-in micron gauge and adjustable high/low vacuum alarms
- Temperature-compensated system tightness (leak) test
- Internal data logging — up to 9 jobs, up to 7 days (168 continuous hours), USB download
- 2.4GHz wireless — sends/receives readings from Job Link System psychrometers, pipe clamps and refrigerant scales
- 5" diagonal LCD with adjustable blue backlight
- Hermetically sealed sight glass; protected thermocouple jacks
- IP54 water-resistant; A2L/A1/A3 refrigerant compatible, R32 ready
Specifications
- Maximum manifold pressure: 800 psig (5500 kPa)
- Micron gauge operating range: approx. 1–10,000 microns
- Battery: 6 x AA alkaline, ~350 hours typical
- Wireless range: up to ~300m line of sight, 2.4GHz
- Weight: 1.83kg
- Operating environment: 0°C to 50°C, <75% RH
What's Included: SM380VINT manifold, 2 x TC24 wired Type K pipe clamp thermocouples, 1 x ATA1 Type K bead thermocouple with clip, ANC11 padded drawstring case.
Compatible with Fieldpiece Job Link System wireless probes (JL3RH psychrometer, JL3PC/JL3LC pipe clamps, SRS3/SR47 scales) for full digital job documentation.
Model: SM380VINT
