Fieldpiece SC680INT True RMS AC/DC Swivel Clamp Meter
by Fieldpiece
$844.15
The Fieldpiece SC680INT is a 600A True RMS AC/DC clamp meter with a swivel clamp head for awkward conductor access. It combines a dual 10,000-count display and built-in power (kW) measurement with Bluetooth connectivity to the Fieldpiece Job Linkยฎ System App.
Key Features
- Swivel clamp head for hard-to-reach conductors
- True RMS AC/DC current measurement up to 600A
- LED illumination in the clamp jaw
- Low Pass Filter (LPF) for accurate VFD readings
- Single-handed 3-phase rotation test with two leads
- Inrush current mode and capacitor testing
- Dual Type K temperature ports
- Non-contact voltage (NCV) detection
- Magnetic mounting base with flip-out strap
- Wireless to Job Linkยฎ System App via Bluetooth
Specifications
- Current: AC/DC up to 600A
- Resistance: up to 50Mฮฉ
- Frequency (Hz) measurement
- Safety rating: CAT IV 600V / CAT III 1000V
- Display: 10,000-count dual display, 5-min blue backlight
- Measurement rate: 3.3 readings/sec
- Wireless range: up to 305m (1000ft) line of sight
- Battery: 1 x 9V alkaline, ~100 hrs typical
- Dimensions: 301.5 x 79.5 x 50mm; Weight: ~480g with battery
What's Included: SC680INT meter, Molex probe tips, silicone test leads, alligator clip leads, two Type K thermocouples, velcro straps, 9V battery, padded case, operator's manual.
Compatibility: Bluetooth-enabled, pairs directly with the Fieldpiece Job Linkยฎ System App (iOS/Android).
Model: SC680INT
