Fieldpiece SC640 Swivel Head TRMS Clamp Meter
by Fieldpiece
$657.66
The Fieldpiece SC640 is a fully loaded dual display clamp meter with a swivel clamp head and built-in LED jaw flashlight, giving techs full electrical and thermal test capability plus practical field features for tight or dark spaces.
Key Features
- Swivel clamp head with LED jaw flashlight
- Dual display shows two readings at once
- True RMS measurement
- Inrush current, continuity and diode test
- Non-contact voltage detection
- Magnetic strap for hands-free mounting
- Backlit selector dial and LCD
- Integrated lead storage
Specifications
- Display: 5000-count dual display
- AC/DC voltage: up to 600V
- AC current (clamp): up to 400A
- Resistance: 50 MĪ©, 0.1 resolution
- Capacitance, frequency (leads and clamp), duty cycle, DC microamps: yes
- Temperature: Ā°F/Ā°C switchable
- True RMS: yes
- Safety rating: CAT III 600V (minimum)
- Battery: single 9V, approx. 100 hours typical alkaline life
- Backlight: blue, 60-second auto-off
What's Included
SC640 meter, ADLS2 deluxe silicone lead set, ATB1 wrap-tab Type K thermocouple, ASA2 short alligator lead extensions, velcro strap, 9V battery, ANC7 padded case.
Model: SC640
