Fieldpiece HS35 Auto/Manual Ranging Stick Multimeter Kit
by Fieldpiece
$403.88
The Fieldpiece HS35 is an expandable stick multimeter that switches between auto-ranging and manual-ranging modes, supplied as a complete kit with the 400A clamp accessory for HVAC/R electrical and current testing.
Key Features
- Auto and manual ranging modes
- Built-in non-contact voltage detection (Volt Stick)
- 400A AC current with included clamp accessory
- Temperature measurement to 1000°F via K-type thermocouple port
- Microamps DC for flame diode testing
- Magnetic hanger for one-handed use, built-in lead storage
- High voltage and continuity indicators
- Rugged ABS case with rubberised bumpers
Specifications
- Display: 3¾-digit LCD, max reading 3999
- DC voltage: 400mV–600V; AC voltage: 400mV–600V (average sensing, not TRMS)
- DC current: 400µA, 4000µA
- Resistance: 400Ω–40MΩ
- Capacitance: to 400µF; Frequency: to 40MHz
- Temperature: -30 to 1000°F (-34 to 538°C)
- Safety rating: CAT III 600V, UL/CE
- Battery: single 9V alkaline, approx. 300 hours typical
What's Included
HS35 expandable stick multimeter, ACH4 400A amp clamp accessory, ADLS2 deluxe silicone test leads, ASA2 short alligator lead extensions, ATB1 wrap-tab K-type thermocouple, ANC1 deluxe meter case, 9V battery (installed).
Model: HS35
