Fieldpiece ATIR3 Infrared Temperature Accessory Head

The Fieldpiece ATIR3 turns a compatible meter into a non-contact infrared thermometer, with a toggle-on laser sight for precise aiming. It's suited to fast surface temperature checks on ductwork, coils, motor bearings and electrical panels.

Key Features

• Non-contact infrared surface temperature measurement
• 8:1 distance-to-spot ratio with toggle-on/off laser pointer
• Records MIN/MAX temperatures when paired with HS30-series meters
• Works standalone with the EHDL1 electronic handle

Specifications

• Temperature range: 0°F to 752°F (-18°C to 400°C)
• Accuracy: ±2% of reading or 4°F, whichever is greater (32°F–160°F); ±3% of reading or 5.5°F, whichever is greater (0–31°F and 161–752°F)
• Distance-to-spot ratio: 8:1
• Output: millivolt DC proportional to temperature

Compatibility

Plugs into Fieldpiece HS30-series stick meters, the EHDL1 electronic handle, and Fieldpiece data loggers. Works with other DMMs via the AHDL1 adaptor handle.

Model: ATIR3
